Timm Master 12
Timm Master 12 12-strand rope polyester/polyolefine dual fibers
Timm mooring ropes are among the world’s best selling premium mixed polymer ropes and Timm Master 12 is our top seller.
Featuring a high level of UV protection, buoyancy, low torque and a great abrasion resistance, Timm Master 12 ensures a ship’s crew problem free mooring, and owners a cost efficient solution.
Suitable for:
Key Benefits
- Double construction: core of SIGNAL B5 mixed polyolefin yarn covered with high performance Polyester
- High abrasion resistance
- Buoyant
- UV stabilized
- OCIMF approved product
- Class leading strength-to-weight ratio
Product Features
- Construction
- 12-strand plaited
- Fiber
- Mixed Polyolefin/HT Polyester
- Specific gravity
- Approx. 1,00
- Colours
- White
- UV resistance
- Excelent
- Abbrasion resistance
- Very Good
- Water resistance
- < 0,1% absorption
- Heat resistance
- 165-260° (melting)
- Elongation
- 18% at break
| diameter | MBL spliced | MBL spliced | MBL unspliced | MBL unspliced | diameter | MBL spliced | MBL unspliced | Weight |
|
DIA.
|
*
|
*
|
DIA.
|
*
|
||||
| (mm) | (t) | (kN) | (t) | (kN) | (inch) | (lbs) | (lbs) | (kg/m) |
| 24 | 11.7 | 115 | 13.1 | 128 | 1“ | 25.898 | 28.775 | 0.305 |
| 28 | 15.9 | 156 | 17.6 | 173 | 1_1/8“ | 35.003 | 38.892 | 0.358 |
| 32 | 20.7 | 203 | 23 | 226 | 1_5/16“ | 45.726 | 50.807 | 0.540 |
| 36 | 26.2 | 257 | 29.1 | 285 | 1_1/2“ | 57.663 | 64.070 | 0.682 |
| 40 | 32.1 | 315 | 35.7 | 350 | 1_5/8“ | 70.815 | 78.683 | 0.841 |
| 44 | 38.8 | 381 | 43.1 | 423 | 1_3/4“ | 85.585 | 95.094 | 1.016 |
| 46 | 42.3 | 415 | 47 | 461 | 1_7/8“ | 93.273 | 103.637 | 1.110 |
| 48 | 46 | 451 | 51.1 | 501 | 2“ | 101.366 | 112.629 | 1.207 |
| 50 | 49.8 | 489 | 55.4 | 543 | 2_1/16“ | 109.864 | 122.071 | 1.309 |
| 52 | 53.9 | 528 | 59.9 | 587 | 2_1/8“ | 118.766 | 131.963 | 1.415 |
| 56 | 62.3 | 611 | 69.2 | 679 | 2_1/4“ | 137.380 | 152.645 | 1.640 |
| 58 | 66.7 | 654 | 74.1 | 727 | 2_3/8“ | 147.092 | 163.436 | 1.758 |
| 60 | 71.3 | 699 | 79.2 | 777 | 2_1/2“ | 157.209 | 174.676 | 1.880 |
| 64 | 80.9 | 794 | 89.9 | 882 | 2_5/8“ | 178.453 | 198.281 | 2.137 |
| 68 | 91.2 | 895 | 101.4 | 994 | 2_3/4“ | 201.114 | 223.460 | 2.410 |
| 72 | 102.1 | 1001 | 113.4 | 1112 | 3“ | 224.988 | 249.987 | 2.700 |
| 76 | 113.5 | 1113 | 126.1 | 1237 | 3_1/8“ | 250.279 | 278.088 | 3.006 |
| 80 | 125.5 | 1231 | 139.5 | 1368 | 3_1/4“ | 276.784 | 307.538 | 3.328 |
| 82 | 131.8 | 1292 | 146.4 | 1436 | 3_3/8“ | 290.540 | 322.822 | 3.495 |
| 88 | 151.3 | 1484 | 168.2 | 1649 | 3_5/8“ | 333.635 | 370.706 | 4.021 |
| 92 | 165.2 | 1620 | 183.5 | 1800 | 3_3/4“ | 364.187 | 404.652 | 4.392 |
| 96 | 179.6 | 1761 | 199.6 | 1957 | 4“ | 395.952 | 439.946 | 4.779 |
| 100 | 194.6 | 1908 | 216.2 | 2120 | 4_1/16“ | 428.931 | 476.590 | 5.182 |
| 104 | 210.2 | 2061 | 233.5 | 2290 | 4_1/4“ | 463.326 | 514.807 | 5.602 |
| 108 | 226.4 | 2220 | 251.6 | 2467 | 4_1/2“ | 499.138 | 554.598 | 6.037 |
| 112 | 243.1 | 2384 | 270.1 | 2649 | 4_5/8“ | 535.961 | 595.512 | 6.489 |
* MBL guaranteed only for ropes spliced by TIMM ROPES
